Packages and data

First things first. Let’s get ready with the packages and the data we are going to use.

In R, the dataset iris is already loaded in the object iris and we will also need the package aod which contains the wald.test function.

In Julia, we will need to load the package RDatasets for the iris dataset, the package DataFrames in order to work with dataframes and the package GLM for the ftest function.

Oh, and don’t forget our new function wald_test! Assuming you have already downloaded the wald_test.jl file, all you have to do is to load it too¹.

R:

library(aod)

Julia:

using RDatasets, DataFrames, GLM
include("wald_test.jl")
iris = dataset("datasets", "iris");

1. Joint restrictions

First let’s form a regression model using the iris dataset and name it model.

R:

model <- lm(Sepal.Length ~ Petal.Length + Petal.Width, iris)
summary(model)

##
## Call:
## lm(formula = Sepal.Length ~ Petal.Length + Petal.Width, data = iris)
##
## Residuals:
##      Min       1Q   Median       3Q      Max
## -1.18534 -0.29838 -0.02763  0.28925  1.02320
##
## Coefficients:
##              Estimate Std. Error t value Pr(>|t|)
## (Intercept)   4.19058    0.09705  43.181  < 2e-16 ***
## Petal.Length  0.54178    0.06928   7.820 9.41e-13 ***
## Petal.Width  -0.31955    0.16045  -1.992   0.0483 *
## ---
## Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
##
## Residual standard error: 0.4031 on 147 degrees of freedom
## Multiple R-squared:  0.7663, Adjusted R-squared:  0.7631
## F-statistic:   241 on 2 and 147 DF,  p-value: < 2.2e-16

Julia:

model = lm(@formula(SepalLength ~ PetalLength + PetalWidth), iris)

SepalLength ~ 1 + PetalLength + PetalWidth

Coefficients:
──────────────────────────────────────────────────────────────────────────────
              Estimate  Std. Error   t value  Pr(>|t|)  Lower 95%    Upper 95%
──────────────────────────────────────────────────────────────────────────────
(Intercept)   4.19058    0.0970459  43.1815     <1e-84   3.9988     4.38237
PetalLength   0.541777   0.0692818   7.81991    <1e-12   0.40486    0.678694
PetalWidth   -0.319551   0.160453   -1.99156    0.0483  -0.636642  -0.00245875
──────────────────────────────────────────────────────────────────────────────

As you notice, our model includes 2 regressors and an intercept. We also notice that the estimated coefficient of the variable PetalLength is statistically significant with a p-value close to 0, while the variable PetalWidth is statistically insignificant (at 1% significance level) having a p-value = 0.048.

In this situation, assume that we want to test whether the coefficients of these variables are jointly significant different than 0.

To do so, we perform a wald test on both of the coefficients.

R:

wald_results <- wald.test(Sigma = vcov(model), b = coef(model), Terms = 2:3)
wald_results

## Wald test:
## ----------
##
## Chi-squared test:
## X2 = 481.9, df = 2, P(> X2) = 0.0

Julia:

wald_results = wald_test(Sigma = vcov(model), b = coef(model), Terms = 2:3)

Wald test:
----------

Chi-squared test:
X2 = 481.90740153204536, df = 2, P(> X2) = 2.265360705998325e-105

2. Joint restrictions of all the coefficients except of the intercept

For this example, we will create a new variable which is going to be the square of Sepal Length (SepalLength2) and we will fit a new model.

R:

iris <- data.frame(iris, Sepal.Length2 = iris$Sepal.Length^2)
model2 <- lm(Sepal.Width ~ Sepal.Length + Sepal.Length2, iris)

Julia:

iris[:SepalLength2] = iris.SepalLength .^ 2
model2 = lm(@formula(SepalWidth ~ SepalLength + SepalLength2), iris)

SepalWidth ~ 1 + SepalLength + SepalLength2

Coefficients:
─────────────────────────────────────────────────────────────────────────────────
                Estimate  Std. Error   t value  Pr(>|t|)    Lower 95%   Upper 95%
─────────────────────────────────────────────────────────────────────────────────
(Intercept)    6.41584      1.58499    4.04787    <1e-4    3.28352      9.54815
SepalLength   -1.08556      0.536246  -2.02437    0.0447  -2.14531     -0.0258139
SepalLength2   0.0857066    0.044755   1.91502    0.0574  -0.00273979   0.174153
─────────────────────────────────────────────────────────────────────────────────

In essence, this is the F-test which is most of the times printed at the bottom of a regression accompanied by its degrees of freedom and the p-value. This test informs us, whether the regressors are jointly equal to zero, and thus if the regression as a whole is useless. In fact, in this case, simply the (unconditional) mean of the dependent variable would have been as good predictor as all of these variables together.

In R, so far so good. As you can see, at the bottom line of summary(model2) we have what we want.

R:

summary(model2)

##
## Call:
## lm(formula = Sepal.Width ~ Sepal.Length + Sepal.Length2, data = iris)
##
## Residuals:
##      Min       1Q   Median       3Q      Max
## -1.13070 -0.26310 -0.02446  0.25728  1.38725
##
## Coefficients:
##               Estimate Std. Error t value Pr(>|t|)
## (Intercept)    6.41584    1.58499   4.048 8.33e-05 ***
## Sepal.Length  -1.08556    0.53625  -2.024   0.0447 *
## Sepal.Length2  0.08571    0.04476   1.915   0.0574 .
## ---
## Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
##
## Residual standard error: 0.4304 on 147 degrees of freedom
## Multiple R-squared:  0.03783,    Adjusted R-squared:  0.02474
## F-statistic:  2.89 on 2 and 147 DF,  p-value: 0.05877

On the other hand, the regression output in Julia doesn’t provide so much information. To retrieve the information about the F-test we will need to do the following things. What we are actually going to do is to use ANOVA which is an F-test and compare our model (sometimes called full model) with the null model which is a regression without any independent variables except from the constant term. So, first we have to create the null model and then perform an F-test (ANOVA) comparing these two models (using the ftest function from the GLM package).

Julia:

nullmodel2 = lm(@formula(SepalWidth ~ 1), iris)
ftest(model2.model, nullmodel2.model)

        Res. DOF DOF ΔDOF     SSR    ΔSSR     R²    ΔR²     F*  p(>F)
Model 1      147   4      27.2362         0.0378
Model 2      149   2   -2 28.3069 -1.0708 0.0000 0.0378 2.8895 0.0588

Speaking about Julia, not so straight forward, right? Now, what if we could skip all this workaround and just perform a restriction, jointly to all the coefficients except from the intercept? That’s right! We can use our new Julia function wald_test exactly the same way as we did before.

Julia:

wald_results = wald_test(Sigma = vcov(model2), b = coef(model2), Terms = 2:3)

Wald test:
----------

Chi-squared test:
X2 = 5.779097987201187, df = 2, P(> X2) = 0.05560128349216448

But as you are about to notice, our result is a Chi square (Χ^2) test instead of an F-test. If we want to see the equivalent F-test, using some basic knowledge from distribution theory, we can go from a Chi square distribution to an F distribution using the following formula:

\[\frac{\chi^2}{df} = F\]

Where the degrees of freedom from the Chi square distribution is the number of restrictions, and this is also the numerator degrees of freedom from the equivalent F distribution.

Julia:

wald_chi2 = wald_results.result["chi2"].chi2
wald_df = wald_results.result["chi2"].df
fstat = wald_chi2 / wald_df

2.8895489936005934

Now that we have the F statistic, we could calculate the p-value which corresponds to the value of the F statistic on the pdf (probability density function) of the F distribution. But this is already too much work for something like this… Once again, we can skip this mess just by asking our new wald_test function to perform an F test for our joint restrictions. All we need is to add the denominator degrees of freedom dendf.

Julia:

dendf = nrow(iris)-length(coef(model2))
wald_results = wald_test(Sigma = vcov(model2), b = coef(model2), Terms = 2:3, df = dendf)

Wald test:
----------

Chi-squared test:
X2 = 5.779097987201187, df = 2, P(> X2) = 0.05560128349216448

F test:
W = 2.8895489936005934, df1 = 2, df2 = 147, P(> W) = 0.05876576520988747

As you notice, the p-values of the \(x^2\) and the F tests are very close but not identical. But as the denominator degrees of freedom is getting larger (i.e. as the number of observations rises or the number of coefficients is getting smaller), the p-value of the F test is getting closer and closer to the p-value of the \(x^2\) test.

3. Joint restrictions of all the coefficients including the intercept

When I faced the previous problem I thought I could take the long way and perform an ANOVA, just to get the job done. That was until I faced the next problem. Consider the problem where you want to test whether all the regression’s coefficients including the intercept are jointly equal to zero. What is the null model in this case? It’s not even the sample mean of the dependent variable as in the previous case. And would it even be nested to our full model? This is the situation which led me to create the wald test function for Julia.

See how easy it is to test if all the coefficients are equal to 0 or whether the intercept, the first and the second coefficients are respectively equal to 4.2, 0.54 and -0.3. In both cases, the \(x^2-test\)and the F-test come to the same conclusion.

Julia:

model

SepalLength ~ 1 + PetalLength + PetalWidth

Coefficients:
──────────────────────────────────────────────────────────────────────────────
              Estimate  Std. Error   t value  Pr(>|t|)  Lower 95%    Upper 95%
──────────────────────────────────────────────────────────────────────────────
(Intercept)   4.19058    0.0970459  43.1815     <1e-84   3.9988     4.38237
PetalLength   0.541777   0.0692818   7.81991    <1e-12   0.40486    0.678694
PetalWidth   -0.319551   0.160453   -1.99156    0.0483  -0.636642  -0.00245875
──────────────────────────────────────────────────────────────────────────────

dendf = nrow(iris)-length(coef(model))
wald_results = wald_test(Sigma = vcov(model), b = coef(model), Terms = 1:3, df = dendf).result

Wald test:
----------

Chi-squared test:
X2 = 32008.931513284944, df = 3, P(> X2) = 0.0

F test:
W = 10669.643837761649, df1 = 3, df2 = 147, P(> W) = 1.0022050012971983e-171

wald_results = wald_test(Sigma = vcov(model), b = coef(model), Terms = 1:3, H0 = [4.2, 0.54, -0.3], df = dendf).result

Wald test:
----------

Chi-squared test:
X2 = 0.763308780543053, df = 3, P(> X2) = 0.858221426416421

F test:
W = 0.25443626018101767, df1 = 3, df2 = 147, P(> W) = 0.8580771658399398

Feel free to download, modify and use the code!

Comments of all kinds are more than welcome!
